News

  • VNS reveals new 8K-in / 4k-out video wall controller G900 with up to 5 windows MultiViewer function. G901(single channel), G902 (dual channels) and G904 (4 channels) are the models in 4k output product line. When it builds a video wall with 4x UHD monitors, user can display one 4k/2k or 8k/2k content across entire video wall as well as independent true 4k/2k 60Hz 4:4:4 video in each 4k monitor to get pixel to pixel highest video quality. Maximum videos that can be displayed in 4 monitor video wall is eight. True 8k/2k video wall with pixel to pixel video quality. G904 is also the world’s first Ultra HD Quad view MultiViewer with one PIP window inside and lets user monitor up to 5x independent HDMI videos on one Ultra HD display. The PIP image can be located at any position with programmable size up to full HD. G902 can display one Triple split view or 2/3: 1/3 split view for one monito. One G904 can display two triple split view for two monitors simultaneously. The monitors for MultiViewer can be installed at landscape or portrait directions. All the input videos can be up to 4096*2160 @60Hz or 8k/2k @30Hz. With full frame re-synchronization on every input, user can monitor any combination of SD, HD and Ultra HD formats and frame rates at the same time on the same display. G902 application case study: in additon to PIP/POP, below are examples for G902 multiView application. G904 application case study: in additon to PIP/POP, below are examples for G904 multiView applications. It can display one 4 windows multiviewer with PIP on the top or two Triple Split View at the same time with one at landscape and another one at portrait position. 10x HDMI2.0 UHD input ports are designed in G904. Four HDMI 2.0 outputs. All G900 is integrated with programmable output resolution in the range H=800-4096, V=720-3840 or up to 4096*2400 @60Hz. BT2020 HDR10 10-bit input signal can be supported by G900 with full range 10-bit RGB output to provide the highest video details. It is integrated with 10-bit high end video scaler and supports 3D motion adaptive de-interlace, low angle smooth algorithm and 3:2/2:2 film mode cadence. Besides MultiViewer and video wall applications, G900 can be an ideal front end processor for big scale projector edge blending system and LED wall which is required specific signal resolution to get the best video quality. Case study for projector edge blending system: User can use one channel processor G901 or multi-channel processor G902/G904 as front end to provide PIP/POP and aspect ratio adjustment across entire screen. User can use G902 to get up to 4 discrete videos display and G904 can provide up to 8 discrete video in 4 projector edge blending system. Case study for LED applications: G900 can crop specific region image to remove blanking border of the image and output specific resolution to LED display. It can aslo split high resolution content up to 8k/2k into different sections  for multiple LED modules together with PIP/POP or multiViewer functions for LED wall.  G901 is available in the market and G902 & G904 will be available in early Q4-2020.

  • EASTWITH is a Korea professional company for digital signage and new media applications. EASYWITH built a 12 projector display system with GeoBox G804 and M804 in Timeless Media Art at Kyoung Ju. Please see You-Tube video at below link. If you need further assistance in Korea, please contact Electrosmith at below website:  https://www.electrosmith.co.kr/

  • Electrosmith built a circle projection system for Korea Pohang City Theme Park with 8 units of Panasonic PT-RZ660 WUXGA laser projector and two GeoBox G-704 edge blending processor. The content is from one PC with Nvidia Quadro P4000 display card to provide a content up to 13,340*1200 output resolution. GeoBox provides a easy setup, simple and reliable solution. User even can accomplish this kind of setup through IR remote controller. https://youtu.be/AOoXxMZHFAk

  • VNS India distributor S-Cube promotes GeoBox G-602 Edge Blending processor with Sony Projectors at the New Laser Projector launch by Sony at Mumbai on 21st June 2017. It showed seamless high quality impressive video.

  • We are very honor to share the news from our Japan Distributor--Japan Material that the world largest Digital Art Meseum created by teamLab adopted more than 100 units of GeoBox together with 470 Epson projectors for complete project. Mori Building Digital Art Museum covers more than 10,000 square meters and is located in Tokyo Odaiba Palette Town. It opens on June-21-2018. Please see more details at below website: https://jmgs.jp/case/geobox_teamlab.html

  • System integrator Pro-2000 established one six projector edge blending system with GeoBox for World Flora Exposition in Taichung city. This exposition will open from Nov-03 2018 to April-24 2019. https://youtu.be/8V-kSlpuW84

  • Japan Sharp had launched brand-new ultra-short throw laser proejctor PG-LU400U in Digital Singnage Japan-2017 exhibition. Two laser projectors showed seamless edge blending image by GeoBox G-602. Superior video quality was obtained through vivid color and high contrast ratio of the projector together with GeoBox outstanding edge blending performance. GeoBox G-602 was recommended and put into Sharp product catalog for the application in edge blending.

  • GeoBox G-700 series multiple channel edge blending processor was used in Korea for pixel mapping project in one national museum. The system used 8 projectors to build a curved wall edge blending together with irregular curved pixel mapping. It provided superior video quality.

  • GeoBox is multiple function processor. It can combine the projector images from different walls and floor into one big image for AR/VR applications.  Below are the functions implemented in AR/VR applications: Image position adjustment and geometry alignment Image rotation to match projector installation angle and direction. Split the image into different sections and assign each section to different projector. Adjust image scaling ratio (scaling factor). Edge blending Edge mask unnecessary area All the functions can be implemented through GeoBox without PC or software. It pro vides a easy setup, flexible, reliable and cost effective solution. lease see YouTube at below website:  https://youtu.be/W4rq9ukG6pY

  • Vistron used 12x G-602 for 24x Christie H-series projectors in Vietnam Quang Ninh Project. The screen is 35m*18m dual curve. Signal source is Coolux Quad Server (8k/4k). GeoBox provides flexible and easy installation / setup for important edge blending projects worldwide.

  • GeoBox video wall controller was adopted in Taipei Main Station with 120 units of 55" Sharp LCD in Taiwan.

  • GeoBox had been demo by Japan Material Co. LTD. in 2016 Japan Digital Signage Exhibition. VNS and GeoBox logo had been highlighted with detailed illustration for G-403 and G-202. Four screen at irregular position with GAlign PC tool to show the ability of G-403 in creative video wall and easy handle of the system setup. In G-202 demo, one iPhone output has been fed into two TV. One TV is at normal direction and another one is at portrait direction. The image in normal TV can only show portion image of iPhone without processing of G-202. Another portrait TV processed by G-202 can show full screen image of iPhone. This is to show the ability of GeoBox in image cropping and scaling up/down ability with superior video quality. Japan Material Co. LTD. had prepared a 12 pages color Product Line-Up brochure to introduce full product line of GeoBox. We are great to have a good partner in Japan.
